Features
n
2.54 mm pitch & height
n
2 to 6 precious metal contacts
n
End-to-end stackable
n
Twin hot contacts (symmetrical pad layout)
n
Pick & place compatible
n
High cycle life
M
PL
IA
NT
n
RoHS compliant* - see processing
**
HA
information for RoHS compliant surface
mount components
n
Halogen free**
*R
oH
S
Insulator .... Glass reinforced thermoplastic,
Materials & Finishes
*R
oH
S
CO
70AA/Male - Modular Contact
Product Dimensions
LE
AD
F
RE
E
A 0.20
(A .008)
HORIZONTAL
ENGAGEMENT
CONTACT WIPE
7.09
(.279)
MATING
SURFACE
20
VERTICAL
ENGAGEMENT
1.27
(.050)
Contact ...................................Copper alloy
Finish
Underplating....................... 30
µ”
min. Ni
Contact Area ......... 30
µ”
min. Au over Ni
Electrical
Current Rating....................... 3 A/contact
Voltage Rating..................................60 V
Contact Resistance ....... 25 mohms max.
Dielectric Voltage .....................AC 500 V
Insulating Resistance .. 1000 Mohms min.
Operating Temperature
........................................-55 °C to 125 °C
Mechanical
Vibration ........................ 30 G, 10-2K Hz,
0.06 inches D.A.
Shock ............................................ 100 G
Normal Force ................... 80 grams min.
at a working height of
0.25 mm (0.010 inches)
Durability ................... 50,000 cycles min.
Contact Resistance after
50,000 Cycles .............................. 50 mΩ
MSL ..........................................................1
ESD Rating (HBM) .................................3B
UL 94V-0 rated, black
Operating Characteristics
Ro VE LEA
HS RS D
C ION FRE
OM S E
PL AR
IA E
NT
*
0.18
(.007)
2.54
(.100)
Recommended PWB Layout
2.26
(.089)
TYP.
1.27
TYP.
(.050)
1
0.9
(.035)
CONTACT NUMBERS
2
4
3
5.18 9.70
(.204) (.382)
TYP. TYP.
2.54
CONTACT SPACING
(.100)
2.54
(.100)
TYP.
1
TERMINAL NUMBERS
2
3
4
How to Order
70AA J - 4 - M 0 G
Model
Terminal Style
J = SMT
Number of Contacts (N)
2 through 6
Gender
M = Male
Options
0 = Standard
Electrical Schematic
8.48
6.15 (.334)
(.242)
1
1
8
2
2
7
3
3
6
4
4
5
8
Packaging Option (MSL-1)
__ = Tube
G = Embossed Tape (750 pcs. per reel)
7
0.76
(.030)
TYP.
6
5
2-6 POSITIONS AVAILABLE
Number of
Contacts
2
Dimension
A
5.00
(.197)
7.54
(.297)
10.20
(.397)
12.62
(.497)
15.16
(.597)
±0.3
TOLERANCES:
UNLESS OTHERWISE NOTED
(±.012)
MM
DIMENSIONS:
(INCHES)
* RoHS Directive 2002/95/EC Jan. 27, 2003 including
annex and RoHS Recast 2011/65/EU June 8, 2011.
