Rev.B
IRMCF188
High Performance Sensorless Motor Control IC
Description
IRMCF188 is a high performance Flash based motion control IC designed and optimized for complete air
conditioner control which contains two computation engines integrated into one monolithic chip. One is the
TM
Flexible Motion Control Engine (MCE ) for sensorless control of permanent magnet motors or induction motors;
the other is an 8-bit high-speed microcontroller (8051). The user can program a motion control algorithm by
connecting these control elements using a graphic compiler. Key components of the complex sensorless control
algorithms, such as the Angle Estimator, are provided as complete pre-defined control blocks. A unique
analog/digital circuit and algorithm fully supports single shunt or leg shunt current reconstruction. IRMCF188
performs a PFC (Power Factor Correction) function in addition to the motor control. IRMCF188 comes in a 64 pin
QFP package.
Features
MCE
(Flexible Motion Control Engine) -
Dedicated computation engine for high efficiency
sinusoidal sensorless motor control
Built-in hardware peripheral for single or two shunt
current feedback reconstruction and analog
circuits
Supports induction machine and both interior and
surface permanent magnet motor sensorless
control
Dedicated PFC PWM for digital PFC control
Loss minimization Space Vector PWM
Three-channel analog output (PWM)
Embedded 8-bit high speed microcontroller (8051)
for flexible I/O and man-machine control
JTAG programming port for emulation/debugger
Serial communication interface (UART)
I2C/SPI serial interface
Three general purpose timers/counters
Two special timers: periodic timer, capture timer
Watchdog timer with independent internal clock
Internal 64 Kbyte flash memory
3.3V single supply
TM
Product Summary
Maximum clock input (f
crystal
)
Maximum Internal clock (SYSCLK)
Maximum 8051 clock (8051CLK)
TM
MCE computation data range
8051 Program Flash
8051/MCE Data RAM
MCE Program RAM
GateKill latency (digital filtered)
PWM carrier frequency
A/D input channels
A/D converter resolution
A/D converter conversion speed
Analog output (PWM) resolution
UART baud rate (typ)
Number of digital I/O (max)
Package (lead free)
Typical 3.3V operating current
60 MHz
120MHz
30MHz
16 bit signed
52KB
4KB
12KB
2 μsec
20 bits/ SYSCLK
10
12 bits
2 μsec
8 bits
57.6 Kbps
24
QFP64
30mA
Base Part Number
IRMCF188
IRMCF188
Package Type
LQFP64
LQFP64
Standard Pack
Form
Tape and Reel
Tray
Quantity
1500
1600
Orderable Part Number
IRMCF188TR
IRMCF188TY
1
www.irf.com
© 2014 International Rectifier
March 10, 2017
IRMCF188
Table of Contents
1 Overview .............................................................................................................................. 5
2 Pinout ................................................................................................................................... 6
3 IRMCF188 Block Diagram and Main Functions .................................................................... 7
4 Application connection and Pin function ............................................................................... 9
4.1 8051 Peripheral Interface Group ........................................................................................ 10
4.2 Motion Peripheral Interface Group ...................................................................................... 11
4.3 Analog Interface Group ...................................................................................................... 12
4.4 Power Interface Group ....................................................................................................... 12
4.5 Test Interface Group .......................................................................................................... 12
5 DC Characteristics ............................................................................................................. 14
5.1 Absolute Maximum Ratings ................................................................................................ 14
5.2 System Clock Frequency and Power Consumption ............................................................ 14
5.3 Digital I/O DC Characteristics ............................................................................................. 15
5.4 Analog I/O DC Characteristics ............................................................................................ 16
5.5 Under Voltage Lockout DC characteristics ......................................................................... 17
5.6 Itrip comparator DC characteristics .................................................................................... 17
5.7 CMEXT and AREF Characteristics ..................................................................................... 17
6 AC Characteristics.............................................................................................................. 18
6.1 Digital PLL AC Characteristics............................................................................................ 18
6.2 Analog to Digital Converter AC Characteristics .................................................................. 19
6.3 Op amp AC Characteristics ................................................................................................ 20
6.4 SYNC to SVPWM and A/D Conversion AC Timing ............................................................. 21
6.5 GATEKILL to SVPWM AC Timing ...................................................................................... 22
6.6 Itrip AC Timing ................................................................................................................... 22
6.7 Interrupt AC Timing ............................................................................................................ 23
6.8 I2C AC Timing .................................................................................................................... 24
6.9 SPI AC Timing .................................................................................................................... 25
6.10 UART AC Timing .............................................................................................................. 27
6.11 CAPTURE Input AC Timing .............................................................................................. 28
6.12 JTAG AC Timing ............................................................................................................... 29
7 I/O Structure ....................................................................................................................... 30
8 Pin List ............................................................................................................................... 34
9 Package Dimensions .......................................................................................................... 36
10 Part Marking Information .................................................................................................... 37
11 Qualification Information ..................................................................................................... 37
2
www.irf.com
© 2014 International Rectifier
March 10, 2017
IRMCF188
List of Tables
Table 1. Analog channel sensing functions in Leg and Single Shunt Modes ........................... 12
Table 2. Absolute Maximum Ratings ....................................................................................... 14
Table 3. System Clock Frequency ........................................................................................... 14
Table 4. Digital I/O DC Characteristics .................................................................................... 15
Table 6. Analog I/O DC Characteristics ................................................................................... 16
Table 7. UVcc DC Characteristics ........................................................................................... 17
Table 8. Itrip DC Characteristics .............................................................................................. 17
Table 9. CMEXT and AREF DC Characteristics ...................................................................... 17
Table 10. PLL AC Characteristics ............................................................................................ 18
Table 11 . A/D Converter AC Characteristics .......................................................................... 19
Table 12 Current Sensing OP Amp AC Characteristics ........................................................... 20
Table 13. SYNC AC Characteristics ........................................................................................ 21
Table 14. GATEKILL to SVPWM AC Timing ........................................................................... 22
Table 15. Itrip AC Timing ......................................................................................................... 22
Table 16. Interrupt AC Timing .................................................................................................. 23
Table 17. I2C AC Timing ......................................................................................................... 24
Table 18. SPI Write AC Timing ................................................................................................ 25
Table 19. SPI Read AC Timing ................................................................................................ 26
Table 20. UART AC Timing ..................................................................................................... 27
Table 21. CAPTURE AC Timing .............................................................................................. 28
Table 22. JTAG AC Timing ...................................................................................................... 29
Table 23. Pin List ..................................................................................................................... 35
3
www.irf.com
© 2014 International Rectifier
March 10, 2017
IRMCF188
List of Figures
Figure 1. Typical Application Block Diagram Using IRMCF188 .................................................................................5
Figure 2. Pinout of IRMCF188 ....................................................................................................................................6
Figure 3. IRMCF188 Block Diagram ...........................................................................................................................7
Figure 4. IRMCF188 Leg Shunt Connection Diagram ................................................................................................9
Figure 5. IRMCF188 Single Shunt Connection Diagram ......................................................................................... 10
Figure 6. Crystal circuit example ............................................................................................................................. 18
Figure 7. Voltage droop and S/H hold time ............................................................................................................. 19
Figure 8 Op amp output capacitor ........................................................................................................................... 20
Figure 9. SYNC timing ............................................................................................................................................. 21
Figure 10. Gatekill timing ......................................................................................................................................... 22
Figure 11. ITRIP timing ............................................................................................................................................ 22
Figure 12. Interrupt timing ....................................................................................................................................... 23
2
Figure 13. I C Timing ............................................................................................................................................... 24
Figure 14. SPI write timing ...................................................................................................................................... 25
Figure 15. SPI read timing ....................................................................................................................................... 26
Figure 16. UART timing ........................................................................................................................................... 27
Figure 17. CAPTURE timing .................................................................................................................................... 28
Figure 18. JTAG timing ............................................................................................................................................ 29
Figure 19. PWMUL/PWMUH/PWMVL/PWMVH/PWMWL/PWMWH output ............................................................ 30
Figure 20. All digital I/O except motor PWM output ................................................................................................ 30
Figure 21. RESET, GATEKILL I/O .......................................................................................................................... 31
Figure 22. Analog input ........................................................................................................................................... 31
Figure 23. ADCL pin input structure ........................................................................................................................ 31
Figure 24 Analog operational amplifier output and AREF I/O structure ................................................................. 32
Figure 25. VSS,AVSS pin I/O structure ................................................................................................................... 32
Figure 26. VDD1,VDDCAP pin I/O structure ........................................................................................................... 32
Figure 27. XTAL0/XTAL1 pins structure .................................................................................................................. 33
4
www.irf.com
© 2014 International Rectifier
March 10, 2017
IRMCF188
1 Overview
IRMCF188 is a new generation International Rectifier integrated circuit device primarily designed as a one-chip
solution for complete inverterized appliance motor control applications. Unlike a traditional microcontroller or
DSP, the IRMCF188 provides a built-in closed loop sensorless control algorithm using the unique Flexible Motion
TM
TM
Control Engine (MCE ) for permanent magnet motors as well as induction motors. The MCE consists of a
collection of control elements, motion peripherals, a dedicated motion control sequencer and dual port RAM to
map internal signal nodes. IRMCF188 also employs a unique single shunt current reconstruction circuit to
eliminate additional analog/digital circuitry and enables a direct shunt resistor interface to the IC, while still
supporting leg shunt current sensing. Motion control programming is achieved using a dedicated graphical
TM
compiler integrated into the MATLAB/Simulink development environment. Sequencing, user interface, host
communication, and upper layer control tasks can be implemented in the 8051 high-speed 8-bit microcontroller.
The 8051 microcontroller is equipped with a JTAG port to facilitate emulation and debugging. Figure 1 shows a
typical application schematic using the IRMCF188 in leg shunt mode.
IRMCF188 contains 64K bytes of Flash program memory and comes in a 64-pin QFP package.
Host
communication
Appliance Inverter
With PFC
Galvanic
isolation
PFC gate drive
Passive
EMI
Filter
IRMCF188
Power
Supply
IRS2630D
Motor
(PMSM or IM)
3.3V
UART interface
to Front Panel
Digial I/O
Analog Input
2
22
6
Figure 1. Typical Application Block Diagram Using IRMCF188
5
www.irf.com
© 2014 International Rectifier
March 10, 2017
