710-106/107/370 and 710-108/109/371
Metal “Y” and “T” Transitions
for Series 72 & 74 Tubing and Series 75 Conduit
E
Sym
B
J
M
N
NC
NF
T
Z1
Adapters and
Transitions
"B" End
E
"A" End
D
Metal “T” & “Y” Transitions for use with Transition Fittings
How To Order
Product
Series
Finish
(Table II)
“B” End Dash No.
710
-
106 M
Y Transition Material
106
= Aluminum
107
= Brass
370
= Stainless Steel
T Transition Material
108
= Aluminum
109
= Brass
371
= Stainless Steel
A24 B08 C16
“A” End Dash No.
“C” End Dash No.
"B" End
G
"A" End
"C" End
"C" End
F
H Thread Typ
H Thread Typ
"Y" Transitions
710-106/107/370
Table II: Finish
Finish
Olive Drab over Cadmium Plate
Gold Iridite over Cadmium Plate
over Nickel
Electroless Nickel
Olive Drab over Cadmium Plate
over Nickel
Zinc Cobalt, Olive Drab
Olive Drab over Cadmium Plate
over Electroless Nickel
(1000 Hour salt Spray)
Bright Dip Cadmium over Nickel
Passivate
"T" Transitions
710-108/109/371
Table III: Conduit Dash No./Dimensions
Dash No.
06
08
09
10
12
14
16
20
24
28
32
40
48
56
64
80
Conduit Size
(Ref)
72
74
75
06
-
09
-
12
14
16
20
24
28
32
40
48
-
-
-
06
-
09
10
12
14
16
20
24
28
32
40
48
56
64
-
-
08
09
-
12
-
16
20
24
-
32
40
48
56
64
80
H Thread
Class 2A
7/16 - 28 UNEF
1/2 - 20 UNF
9/16 - 24 UNEF
9/16 - 24 UNEF
5/8 - 24 UNEF
11/16 - 24 UNEF
3/4 - 20 UNEF
7/8 - 20 UNEF
1 - 20 UNEF
1 3/16 - 18 UNEF
1 5/16 - 18 UNEF
1 1/2 - 18 UNEF
1 3/4 - 18 UNS
2 - 18 UNS
2 1/4 - 16 UN
2 3/4 - 16 UN
D
Max
1.97 (50.0)
1.97 (50.0)
2.13 (54.1)
2.13 (54.1)
2.22 (56.4)
2.37 (60.2)
2.37 (60.2)
2.69 (68.3)
2.75 (69.9)
3.06 (77.7)
3.28 (83.3)
3.59 (91.2)
4.23 (107.4)
5.00 (127.0)
5.00 (127.0)
5.70 (144.8)
E
Max
1.20 (30.5)
1.20 (30.5)
1.30 (33.0)
1.30 (33.0)
1.34 (34.0)
1.49 (37.8)
1.49 (37.8)
1.70 (43.2)
1.84 (46.7)
2.09 (53.1)
2.23 (56.6)
2.50 (63.5)
2.96 (75.2)
3.50 (88.9)
3.50 (88.9)
4.10 (104.1)
F
Max
1.33 (33.8)
1.35 (34.3)
1.43 (36.3)
1.43 (36.3)
1.47 (37.3)
1.58 (40.1)
1.65 (41.9)
1.78 (45.2)
1.85 (47.0)
2.09 (53.1)
2.43 (61.7)
2.65 (67.3)
3.15 (80.0)
3.40 (86.4)
3.75 (95.3)
4.25 (108.0)
G
Max
.81 (20.6)
.84 (21.3)
.88 (22.4)
.88 (22.4)
.91 (23.1)
.94 (23.9)
.94 (23.9)
1.03 (26.2)
1.13 (28.7)
1.16 (29.5)
1.16 (29.5)
1.28 (32.5)
1.53 (38.9)
1.69 (42.9)
1.87 (47.5)
2.13 (54.1)
* Consult factory for adapters using 3.000 inch (76.2) conduit
