LAST TIME BUY: AUGUST 31, 2014. CLICK HERE FOR OBSOLESCENCE NOTICE OF FEBRUARY 2014.
www.murata-ps.com
FEATURES
■
■
■
■
■
■
HPR1XXC
Series
0.75 Watt Single Output DC/DC Converters
Low
Co
st
Cost
o
Multiple
Package
Styles
e
Interna
l
Internal
Input
and
Output
a
Non-Co
nductive
Case
Non-Conductive
C
ase
o
Filtering
g
NOT RECOMMENDED
FOR NEW DESIGNS
The
H
PR1XXC
Se
ries
uses
ad
vance
circuit design and packaging technology to deliver superior reliability and
HPR1XXC Series
e
advanced
d
e
perfo
rmance.
170kHz push-pull
o
h
performance.
A
1
70kHz
push
-pull
oscillator is used in the input stage. Beat-frequency oscillation problems are
reduc
ed
c
s
R
reduced
when
us
ing
the
HPR
1XXC
Series with high frequency isolation amplifiers.
using
HPR1XXC
Reduced parts count and high efficiency add to the reliability of the HPR1XXC Series. The high efficiency of the
HPR1XXC Series means less internal power dissipation, as low as 190mW.
With reduced heat dissipation the HPR1XXC Series can operate at higher temperatures with no degradation. In
addition, the high efficiency of the HPR1XXC Series means the series is able to offer greater than 10 W/inch3 of
output power density. Operation down to no load will not impact the reliability of the series, although a >1mA
minimum load is needed to realize published specifications.
The HPR1XXC Series provides the user a low cost converter without sacrificing reliability. The use of surface mounted
devices and advanced manufacturing technologies make it possible to offer premium performance and low cost.
High Output Power Density:
10 Watts/Inch
3
Extended Temperature Range:
-25°C to +85°C
Efficiency to 79%
RoHS Compliant
■
■
■
As of September 2014, ONLY the following part numbers will be available: HPR100C; HPR102C; HPR103C; HPR104C;
HPR105C; HPR106C; HPR107C; HPR110C; HPR116C; HPR117C; HPR118C; HPR120C
SPECIFICATIONS
All specifications are typical at T
A
= +25°C nominal input voltage unless otherwise specified.
PRODUCT SELECTION CHART
Model
HPR100C
HPR101C
HPR102C
HPR103C
HPR104C
HPR105C
HPR106C
HPR107C
HPR110C
HPR111C
HPR112C
HPR113C
HPR116C
HPR117C
HPR118C
HPR120C
HPR122C
HPR123C
HPR108C
HPR109C
HPR114C
HPR115C
HPR119C
HPR121C
Nominal Input
Voltage
V
DC
5
5
5
5
5
5
12
12
12
12
15
15
15
15
24
24
24
24
12
12
15
15
24
24
Rated Output
Voltage
V
DC
5
12
15
±5
±12
±15
5
12
±12
±15
5
12
±12
±15
5
15
±12
±15
15
±5
15
±5
12
±5
Rated Output
Current
mA
150
62
50
±75
±30
±25
150
62
±30
±25
150
62
±30
±25
150
50
±30
±25
50
±75
50
±75
62
±75
Input Current
No Load
20
20
20
20
20
20
10
10
10
10
8
8
8
8
8
8
8
8
10
10
8
8
8
8
Rated Load
mA
216
212
212
218
212
200
90
81
81
81
72
72
63
63
48
45
45
45
81
88
72
72
48
45
Reflected Ripple
Current
mAp-p
10
5
5
5
5
5
5
5
5
5
5
5
5
5
15
15
15
15
5
5
5
5
15
15
Efficiency
%
69
70
71
68
68
75
69
77
74
77
69
69
76
79
65
76
67
69
77
71
69
69
65
69
Recommended Alternatives
NMR100C / MER1S0505SC
NMR101C / MER1S0512SC
NMR102C / MER1S0515SC
NMA0505SC / MEA1D0505SC
NMA0512SC / MEA1D0512SC
NMA0515SC / MEA1D0515SC
NMR106C / MER1S1205SC
NMR107C / MER1S1212SC
NMA1212SC / MEA1D1212SC
NMA1215SC / MEA1D1215SC
MER1S1505SC
MER1S1512SC
MEA1D1512SC
MEA1D1515SC
MER1S2405SC
MER1S2415SC
MEA1D2412SC
MEA1D2415SC
NMR108C / MER1S1215SC
NMA1205SC / MEA1D1205SC
MER1S1515SC
MEA1D1505SC
MER1S2412SC
MEA1D2405SC
OBSOLETE
OBSOLETE
OBSOLETE
OBSOLETE
OBSOLETE
OBSOLETE
*
LAST TIME BUY: AUGUST 31, 2014. CLICK HERE FOR OBSOLESCENCE NOTICE OF FEBRUARY 2014.
OBSOLETE
NOT RECOMMENDED FOR NEW DESIGNS
*
*
*
*
*
*
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
TDC_HPR1xxC.D01
Page 1 of 4
HPR1XXC
Series
SPECIFICATIONS, ALL MODELS
Specifications are at T
A
= +25°C nominal input voltage unless otherwise specified.
0.75 Watt Single Output DC/DC Converters
MIN
TYP
MAX
UNITS
PARAMETER
INPUT
INPUT
Voltage Range
CONDITIONS
4.5
5
5.5
VDC
10.8
12
13.2
VDC
13.5
15
16.5
VDC
21.6
24
26.4
VDC
Voltage Rise Time See Typical Performance Curves & Application Notes: “Capacitive Loading Effects on Start-Up of DC/DC Converters”
OUTPUT
Rated Power
750
mW
Voltage Setpoint Accuracy
Rated Load, Nominal V
IN
±5
%
Ripple & Noise
BW = DC to 10MHz
150
200
mVp-p
BW =10Hz to 2MHz
30
40
mVrms
Voltage (Over Input Voltage Range) 1mA to Rated Current, V
OUT
= 5V
4.75
7
VDC
1mA to Rated Current, V
OUT
= 12V
11.40
15
VDC
1mA to Rated Current, V
OUT
= 15V
14.25
18
VDC
Temperature Coefficent
.01
.05
%/ °C
REGULATION
Load Regulation (All other modes)
Rated Load to 1mA Load
3
%
GENERAL
ISOLATION
Rated Voltage
750
VDC
Test Voltage
60 Hz, 10 Seconds
750
Vrms
Resistance
10
G
Capacitance
25
100
pF
Leakage Current
V
ISO
= 240VAC, 60Hz
2
8.5
Arms
Switching Frequency
170
kHz
Frequency Change
Over Line and Load
24
%
Package Weight
3
g
MTTF per MIL-HDBK-217, Rev. F*
Circuit Stress Method
Ground Benign
T
A
= +25°C
7.9
MHr
Fixed Ground
T
A
= +35°C
1.9
MHr
Naval Sheltered
T
A
= +35°C
1.2
MHr
Airborne Uninhabited Fighter
T
A
= +35°C
300
kHr
TEMPERATURE
Specification
-25
+25
+85
°C
Operation
-40
+100
°C
Storage
-40
+110
°C
GENERAL
OUTPUT
SOLDERING INFORMATION
The HPR1XXC devices are intended for wave soldering or manual soldering.
They are not intended to be subject to surface mount processes under any circumstances.
The normal wave soldering process can be used with these devices where the device is subjected
to a maximum wave temperature of 260°C for a period of no more than 10 seconds. Within this
time and temperature range, the integrity of the device’s plastic body will not be compromised and
internal temperatures within the converter will not exceed 175°C. Care should be taken to control
manual soldering limits identical to that of wave soldering.
www.murata-ps.com/support
TDC_HPR1xxC.D01
Page 2 of 4
HPR1XXC
Series
0.75 Watt Single Output DC/DC Converters
TYPICAL PERFORMANCE CURVES
Specifications are at T
A
= +25°C nominal input voltage and nominal load.
VOUT VS LOAD
(5Vout Models)
5.7
5.5
Vout
Vout
5.3
5.1
4.9
0
40
80
120
160
Output Current (mA)
VOUT VS LOAD
(±12Vout Models)
12.6
12.5
12.4
Vout
12.3
12.2
12.1
12.0
0
10
20
30
40
Output Current each load (mA)
Vout
Vout
15.5
15.3
15.1
14.9
0
20
40
60
80
Output Current each load (mA)
OSCILLATION FREQUENCY VS
TEMPERATURE
220
Frequency (KHz)
200
180
160
140
80
100
-30
0
30
Temperature (°C)
60
90
15.9
15.7
5.4
5.2
Vout
5.0
4.8
12.0
4.6
0
20
40
60
80
Output Current each load (mA)
VOUT VS LOAD
(15Vout Models)
16.5
16.0
15.5
15.0
14.5
14.0
13.5
0
0.2
0.4
0.6
0.8
1.0
Output Power each load (Watts)
11.9
0
20
40
60
80
Output Current each load (mA)
VOUT VS LOAD
(±15Vout Models)
VOUT VS LOAD
(±5Vout Models)
12.5
12.4
12.3
12.2
12.1
VOUT VS LOAD
(12Vout Models)
EFFICIENCY VS LOAD
90
75
Efficiency (%)
60
45
30
15
0
0
20
40
60
% of Rated Load (%)
SAFE OPERATING AREA
600
LOAD CAPACITANCE vs INPUT RISE TIME
(5 Vout models)
60
LOAD CAPACITANCE vs INPUT RISE TIME
(15 Vout models)
500
50
Total Load Capacitance (uF)
Total Load Capacitance (uF)
400
40
300
30
SAFE OPERATING AREA
200
SAFE OPERATING AREA
20
100
10
0
0
5
10
15
20
25
30
35
Rise Time of Input Voltage (mS)
40
45
50
0
0
5
10
15
20
25
30
35
40
45
50
Rise Time of Input Voltage (mS)
LOAD CAPACITANCE vs INPUT RISE TIME
(12 Vout models)
90
NOTES:
1.) When operated within the SAFE OPERATING AREA as defined by the above curves, the
output voltage of HPR1XXC devices is guaranteed to be within 95% of its steady-state value
within 100 milliseconds after the input voltage has reached 95% of its steady-state value.
2.) For dual output models, total load capacitance is the sum of the capacitances on the
plus and minus outputs.
Total Load Capacitance (uF)
80
70
60
50
40
30
20
10
0
0
5
10
15
20
25
30
35
40
45
50
Rise Time of Input Voltage (mS)
SAFE OPERATING AREA
www.murata-ps.com/support
TDC_HPR1xxC.D01
Page 3 of 4
HPR1XXC
Series
0.75 Watt Single Output DC/DC Converters
MECHANICAL
“SIP” PACKAGE/PINOUT
0.77+0.010"
(19.56+0.25)
0.240+0.010"
(6.09+0.25)
FRONT
VIEW
1
2
4
*5
6
0.397+0.010"
(10.16+0.25)
0.020+0.010"
(0.51+0.25)
0.140"
MIN
(3.56)
0.02+0.002"
(0.51+0.05)
0.18+0.015"
(4.57+0.38)
RIGHT
SIDE
VIEW
Notes:
All dimensions are in inches (millimeters).
GRID: 0.100 inches (2.54 millimeters)
PIN PLACEMENT TOLERANCE: ± 0.015"
MATERIAL: Lead material is phosphor bronze; lead
finish is 100-300 microinches of matte tin over a nickel
barrier layer of 5-40 microinches.
*Common pin not present on single output models.
PIN CONNECTIONS
1.
+VIN
2.
-VIN
4.
-VOUT
5.
COM*
6.
+VOUT
0.01+0.002"
(0.25+0.05)
0.035+0.015"
(0.89+0.38)
BOTTOM
VIEW
ABSOLUTE MAXIMUM RATINGS
Internal Power Dissipation ........................................ 450mW
Short Circuit Duration ................................................ Momentary
ORDERING INFORMATION
HPR
Device Family
HPR Indicates DC/DC Converter
Model Number
Selected from Table of Electrical Characteristics
RoHS Compliant Version
1XX
C
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
ISO 9001 and 14001 REGISTERED
This product is subject to the following
operating requirements
and the
Life and Safety Critical Application Sales Policy:
Refer to:
http://www.murata-ps.com/requirements/
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2014 Murata Power Solutions, Inc.
www.murata-ps.com/support
TDC_HPR1xxC.D01
Page 4 of 4
