SERIAL SERVER WITH
INTERNAL MODEM
PORTSERVER® TS
M MEI
PortServer TS M MEI offers Ethernet and RS-232/422/485
serial connections, with the addition of an internal modem.
The three-port serial servers are ideal for applications
requiring both IP networking and standard phone line dial-up
connectivity for remote access to serial devices.
The embedded modem adds another level of flexibility to the
PortServer TS line. It allows remote hosts to dial-in to a serial
device attached to the Digi serial server, as well as the serial
device to dial-out to a remote location using a standard phone
line. The modem helps to create a PPP connection (TCP/IP
connection over modem) so that applications and devices can
Ethernet and RS-232/422/485 serial connections, with internal
modem for dial-up connectivity to remote serial devices
communicate via an IP network, even when the primary LAN
or WAN is not available. This allows users from a central
location to maintain access to remote serial devices.
Other applications for PortServer TS M MEI include remote
site console management for small branches and remote log-
in via a TCP/IP network for easy troubleshooting, monitoring,
configuration or control.
*The RealPort encryption feature is compatible with AIX, HP-UX, Solaris, Linux,
Windows 2000, Windows XP, Windows 7, Windows 8, Windows 8.1, Windows 10,
Windows Server 2003, Windows Server 2008 and Windows Server 2012. The RealPort
authentication feature is compatible only with Windows 2000, Windows XP, Windows 7,
Windows 8, Windows 8.1, Windows 10, Windows Server 2003, Windows Server 2008 and
Windows Server 2012.
BENEFITS
– Easily connect to remote networks and devices
– Internal v.90/v.92 modem
– 3-port models for application flexibility
– RS-232/422/485 switch-selectable on all ports
– RealPort for COM or TTY port control and
management
– PPP and SSH for creating secure IP network over
serial connection
– Easy IP assignment via DCHP, RARP, ARP-Ping or
Digi utilities
APPLICATION EXAMPLE
REMOTE DIAL-UP
Ethernet
SERVER
WAN
Ethernet
PORTSERVER® TS M MEI
TELEPHONE LINES
RELATED PRODUCTS
RS-252
PortServer®
TS MEI
PortServer®
TS
PortServer®
TS P MEI
PortServer®
TS MEI
Hardened
Digi One®
IAP
Oil & Gas Pipeline
RTU
(Remote Terminal Unit)
SPECIFICATIONS
FEATURES
PortServer® TS 3 M MEI
HTTP/HTTPS, CLI, SNMP (read/write), Digi Port Authority-Remote management diagnostics and auto-discovery tool
UDP/TCP, DHCP/RARP/ARP-Ping for IP Address assignment, PPP, Extended Telnet RFC 2217, Telnet, Reverse Telnet,
Modbus to Modbus/TCP protocol conversion support
SSHv2, Static routing, RIP 1, SSL/TLS
Supports Digi’s Realport® COM port redirector
Link, Activity, Power, Status
AIX, HP-UX, Solaris, Linux®, Windows® 2000, Windows® XP, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10, Windows Server®
2003, Windows Server® 2008, Windows Server® 2012. Note: TCP/UDP socket services are operating system independent
5.25 in x 3.33 in x 0.95 in (13.34 cm x 8.46 cm x 2.42 cm)
2.25 oz (64.00 g)
DIN rail mounting options, Full modem and hardware flow control, Port buffering, RJ45-DB-9F console adapter included for optional
serial configuration
MANAGEMENT
PROTOCOLS
SECURITY
SOFTWARE
STATUS LEDS
OPERATING SYSTEMS
DIMENSIONS (L X W X D)
WEIGHT
OTHER
INTERFACES
SERIAL
PORTS
MODEM
3 RS-232/422/485 RJ-45; Up to 230 Kbps throughput; Signal support for TXD, RXD, RTS, CTS, DTR, DSR, DCD
PORTS
MODEM TYPE
ETHERNET
1 RJ-11
Internal v.90/v.92
PORTS
POWER REQUIREMENTS
1 RJ-45 10/100 Mbps 10/100Base-T (auto-sensing); Full or half duplex
POWER INPUT
POWER SUPPLY (INCLUDED)
POWER CONSUMPTION
PRODUCT SURGE PROTECTION
(ESD):
ENVIRONMENTAL
9-30 VDC
North America: 12VDC/.5A max out; 120VAC in (wall mount); International: 12VDC/.5A max out; 100-240VAC in (small brick)
Typical: 4 W; Max: 6 W
4 kV burst (EFT) per EN61000-4-4, 2 kV surge transient per EN61000-4-5
OPERATING TEMPERATURE
STORAGE TEMPERATURE
RELATIVE HUMIDITY
ETHERNET ISOLATION
SERIAL PORT PROTECTION (ESD)
REGULATORY APPROVALS
-0° C to +50° C (32° F to 122° F)
-40° C to +85° C (-40° F to +185° F)
5% to 90% (non-condensing)
1500 VAC min per IEEE802.3/ANSI X3.263
15 kV human body model
SAFETY
EMISSIONS/IMMUNITY
UL 60950-1, CAN/CSA C22.2 60950-1-03, IEC 60950-1 & CB
CE, FCC Part 15 (Subpart B, Class B), EN55022 Class B, EN55024, AS/NZS 3548, VCCI V-3/99.05, EN61000-3-2
PART NUMBERS
70001899
70001986
DESCRIPTION
PortServer TS 3 M MEI
PortServer TS 3 M MEI (International)
PORTSERVER TS M MEI - FRONT
PortServer TS Family - Front
PORTSERVER
TS M MEI - Back
PortServer
TS M MEI - BACK
Ethernet
LEDs
Ethernet LEDs
LEDs
LEDs
Power
Power
RJ-11
RJ-11
Modem
Modem
DIGI SERVICE AND SUPPORT /
You can purchase with confidence knowing that Digi
is always available to serve you with expert technical support and our industry
leading warranty. For detailed information visit www.digi.com/support.
© 1996-2017 Digi International Inc. All rights reserved.
All trademarks are the property of their respective owners.
DIGI INTERNATIONAL WORLDWIDE HQ
877-912-3444 / 952-912-3444 /
www.digi.com
DIGI INTERNATIONAL GERMANY
+49-89-540-428-0
DIGI INTERNATIONAL JAPAN
+81-3-5428-0261 / www.digi-intl.co.jp
DIGI INTERNATIONAL SINGAPORE
+65-6213-5380
DIGI INTERNATIONAL CHINA
+86-21-50492199 / www.digi.com.cn
91001260
F3/717
